Additional Information on
Nikkor 50mm lenses - Nikkor-S(C) Auto 1:1.2 f=55mm, Noct-Nikkor 58mm f/1.2, Nikkor 50mm f/1.2



Nikon Nikkor-S(C) Auto 1:1.2 f=55mm fast speed Standard Lens

Nikon couldn't just observe the global competition in making the fastest lenses ever. Various lens makers showed their optical abilities by producing faster lenses. ‘Slow’ films (low ISO/ASA number = sensitivity) in the 1950's and 1960's made photographers calling for faster lenses. Coating and the introduction of computers made lens design a bit easier. Nikon managed to produce a fast Nikkor-N 1.1/5cm. for its range finder camera. For the SLR camera it became too difficult, as the rear lens shouldn't protrude into the camera, where it could be damaged by the swinging mirror. That's why Nikon came with a standard prime lens with a slightly longer focal length and a maximum aperture, resulting in the famous Nikkor-S 1.2/55mm., which was introduced in December 1965. All the details of this lens one can find in a special web site. After produced some 175,000 lenses production terminated in April 1978. Early versions may still stated as Nippon Kogaku and later versions simply just stated as "Nikon". There is also an interim Ai-spec 55mm f/1.2 but there was never an Ai-S version for this 55mm as Nikon replacement model was a 50mm f/1.2 which was introduced in July, 1978.

NOTE:- For More detailed info on specific 50~58mm f/1.2 Nikkor lenses, you may CLICK HERE directly to more such resources prepared by Nico van Dijk.

Nikon Nikkor-S auto 55mm f/1.2 standard lens by Nico Nikon Nikkor-S.C auto 55mm f/1.2 standard lens by Nico Rear section lens mount of Nikon Nikkor-S auto 55mm f/1.2 standard lens by Nico

Credit: Images courtesy of Adorama® Inc. "Ebay - Mathew Duren" <ebay@adorama> Website URL: Adorama.com, who also operates a popular Ebay Store. The center image courtesy of "Jone Quinn" <yahuhai@yahoo.com> who also also runs a popular Ebay Store where you can take a visit to scout for his extensive OM used items. Image copyright © 2006 All rights reserved. All images appeared herein are Copyright © 2006 of the respective contributors. All rights reserved. Please respect the visual property of the contributing photographer.

Pre-Ai era of a Nikon auto Nikkor 55mm f/1.2 standard lens  Rear and side view of a Nikon Nikkor-S auto Nikkor 55mm f/1.2 standard lens
Specifications for a typical early version Nikkor-S AUTO 55mm f/1.2 lens

Focal length:
55mm; Maximum aperture: 1:1.2
Lens construction: 7 elements in 5 groups
Picture angle: 43° at infinity
Distance scale: Graduated both in meters and feet up to 0.6m and 2 ft

<<<-- An Ai-Spec Nikkor 55mm f/1.2. Note the NIKKOR-S(C) was replaced with just a "Nikkor". Credit: Image at far left, Shutterblade team URL: Ebay Store, Images at left and the bottom courtesy of Adorama® Inc.@ Ebay Store. All images appeared herein are Copyright © 2006 of the respective contributors. All rights reserved.

Credit: Image(s) courtesy of 'Shutterblade team' (e-mail)who specializes trading of new, used collectable cameras. The Company also operates a popular Ebay Store. All image(s) appeared herein are Copyright © 2005. All rights reserved. Please respect the visual property of the contributing photographer.
A lovely picture of a typical Nikon's Nikkor 55mm f/1.2 standard lens

Optical construction of a typical Nikon's Nikkor 55mm f/1.2 standard lens

PDF for its optical
construction as well
as dimension

Aperture scale: f/1.2 - f/16; Aperture diaphragm: Fully automatic
Meter coupling prong: Integrated (fully open exposure metering); for the later
Ai-spec version, meter coupling ridge provided for Al cameras and meter coupling shoe for non-Ai cameras; Cosmetic different
Attachment size: 52mm (P=0.75); Filter: 52mm screw-in

Dimensions
: 73.5mm dia. X 58.5mm length (2-29/32 in. x 2-9/32 in.); Weight: 420g (14.8 oz); Accessories: 52mm Snap-On front cap (108 - 00 - 400), rear cap type F (108 - 00-01), 52mm screw-in (108 - 00 - 204) or Snap-On (108 - 00 - 200) lens hood, leather case (108 - 01 - 307), plastic case type S (108 - 00 - 300), flexible pouch No. 51 (108 - 00 - 302)
. Solely acts as a general guide for a typical version, actual spec of respective model may be differed from what is listed herein.

Nikon Noct-Nikkor 58mm f/1.2 fast speed aspherical lens This very special lens was introduced in February 1977. It is the first Nikkor with a manual ground aspherical front lens. I have various versions of the 55mm/1.2 and the Noct-Nikkor of which two types exist: the AI-versions and the AIS-version. Both lenses are optically identical. Noct-Nikkor production started in February 1977. As the name of Noct-Nikkor implies, this lens was designed specifically for night shooting and low-light photography. The lens' ultra-fast speed contributes to a bright, easy-to-focus finder image even in dim light levels, and permits the use of faster shutter speeds - a definite advantage in handheld nighttime photography with low available light. To allow the fastest possible shutter speed, the Noct-Nikkor is specially corrected for use at full-aperture.

Three fast speed (f/1.2) Nikkor standard  lenses compared
A side view of an Ai-spec Nikkor lens with f/1.2 apertureHistorically, the appearance of comatic aberration has prevented the photographer from using a large aperture lens of this sort wide open, particularly under conditions such as night scenes which generally include a lot of bright, scattered lights in a dark background. Other photographic uses include available light shooting, snapshots, candid of people, landscapes, electronic flash photography, travel, photojournalism, and full-length portraits in the studio or on location.

<<< -- Size comparison of the NOCT-Nikkor 58mm with other Nikkor large diameter (f/1.2) standard lenses.

With the Noct Nikkor, Nikon designers have employed an aspherical lens surface in its front element for optimum comatic correction at full-aperture, thus delivering the image of bright point objects as they are, without flaring away to the frame corners. Inner reflections are further corrected by the black-finished inner metal surfaces, and the application of Nikon Integrated Coating for reduction of flare and ghost images. Despite its high speed, the improved optical system of the Noct-Nikkor assures virtually distortion-free performance down to the closest focusing distance of 0.5m (17') as well as high-contrast images with optimum resolution. The compact size, on the other hand, allows the use of Nikon 52mm screw-on accessories -the standard for most Nikkor lenses from 20 - 200mm produced during the '70.

Monkey Shadow by Sean Carpenter
Monkey Shadow

Credit: Image courtesy of Sean Carpenter, whose online PORTFOLIO can be accessed at PBase. Image copyright © 2006. All rights reserved. Please respect the visual property of the contributing photographer.

Manual Focus Nikkor classic 58mm f/1.2 NOCT standard lens contributed by Arsenal photo Worldwide
The relatively long production time makes this lens expensive. At full opening it can be used in dim light or even at night. Stray light, internal reflexes and chromatic aberrations, like coma, are well contained to absilute minimal level. Until 1999, some 10,000 lenses were made, where year which saw the production terminated for this fabulous Nikkor classic standard lens.

Credit: Image courtesy of Photo_Arsenal-Worldwide® Germany. The Company also maintains an active EBAY Store, trading many used and new photo equipment of various labels. Photo Aersenal can be contacted at Photo Arsenal Boris Jamchtchik, Altenfurter Str.16a 90475 Nuernberg Germany Tel.: +49 (0) 911/ 4008081 E-Mail: ebayshop@arsenal-photo.com. Arsenal has a office in Hong Kong, headed by Evan Wong. Address is: Ting Shan East Selling-Office Unit 210, 2/f., Mirror Tower, 61 Mody Road, Kowloon, Hong Kong Phone: + 852/23126690 , fax. +852/23126691.Image(s) copyright © 2008. All rights reserved. Please respect the visual property of the contributing photographer.

Technical highlights:

*
Tremendously versatile.
* Large maximum aperture of f/1.2 provides bright and easy-to-focus images in the viewfinder and permits the use of faster shutter speeds - a definite advantage in holding the camera steady.
* Extremely well corrected for coma and spherical aberration - an aspherical front lens element assures optimum correction for coma, particularly at maximum aperture, thus making bright point sources of light near the edges of the picture frame appear as dots rather than comet-shaped blurs.
* Nikon Integrated Coating insures faithful color rendition, while reducing ghost images and flare.
* Improved optical system provides virtually distortion-free performance down to the closest focusing distance of 0.5m (1.7 ft.) as well as high contrast images.
* Extremely well corrected for internal reflections, due to a matte-black finish on all inner metal surfaces.
* Uses popular 52mm filters despite its large maximum aperture.
* Designed especially for dim-light photography, but can be used for any subject, such as candids, travel photography, sports, or weddings.

A Nikon F2A with a Nikkor 58mm f/1.2 standard lens Optical construction of a typical Nikkor 50mm f/1.2 ai standard lens lens optical formula of a Nikkor 50mm f/1.2 ai standard lens
Specifications for NOCT-Nikkor 58mm f/1.2 Aspherical lens

Focal length: 58mm Maximum aperture: 1:1.2
Lens construction: 7 elements in 6 groups
Picture angle: 40° 50' at infinity
Exposure measurement: Automatic

<<< -- Optically both Ai and Ai-S are similar. But I put both illustration of the Ai and Ai-S for comparison.

Nikkor 50mm f/1.2 ai standard lens
Distance scale: Graduated both in meters / feet closes at 0.5m and 1.7 ft to infinity (OO);
Aperture scale: f/1.2 - f/16; Aperture diaphragm: Fully automatic;
Meter coupling prong
:
Via full aperture method; meter coupling ridge provided for Al cameras and meter coupling shoe for non-Ai cameras;
Filter Attachment size
: 52mm (P=0.75); Filter: 52mm screw-in;
Dimensions
: 74mm dia. x 63mm long (overall); 51.5mm extension from flange; Weight: 480g
Accessories
: Snap-On Snap-On (HS-7); Rubber screw-in (HR-2); Lens case: CL-34A hard leatherette, No. 61 soft pouch, or CP-8 plastic
Usable teleconverter:
TC-200*, TC-201S, TC-16A*, TC-14A

*
Only usable with selective AF bodies such as F-801, F-501 etc. to convert manual lenses into a lens with AF function on those bodies. Focal length of the lens in used will also magnify 1.6 times from original. When used at Apertures smaller than f11 at fast shutter speeds, there is occasional uneven exposure. Solely acts as a general guide for a typical version, actual spec of respective model may be differed from what is listed herein.

In-lined with the development of the Ai-full aperture metering system deployed on all Nikon SLRs, by 1978/9, most of the Nikkor standard lenses have also went through one round of general lens dating program and hence, most of them have been converted as an Ai-spec Nikkor. There was actually four different Ai-50mm Nikkor standard lenses offered during this period, namely as 50mm f/1.2, Nikkor 50mm f/1.4, a new Nikkor f/1.8 and an Ai-Nikkor 50mm f/2.0 which was converted from the old model but now it has a familiar Ai-dressing.

Three Nikkor lenses shown in a Nikkor lens catalogue in 1978
NOTE: the Nikkor 50mm f/1.8 probably was introduced later as shown by missing link in this illustration scan of a 1978 Nikkor lens catalogue Similarly, I guess the Nikkor 50mm f/1.2 was not being introduced at the time of print production (Shown is still the 55mm f/1.2 but also an Ai-spec version).

Metering coupling prongs of various versiosn of Nikkor lenses

Nikon Nikkor 50mm f/1.2 (Ai-spec) standard lens. Officially introduced in July 1978 as the successor of the earlier 1.2-55mm. It is one of the brightest standard lens around as well as doubled as the Nikkor that has the fastest lens speed in the lens group. It entered the world market in a new outfit as well as internally with a 7 elements in 6 groups optical arrangement. Besides, the picture angle is 46°, , which is slightly wider than its predecessor's 40° 50. In all aspects this lens performs better than the 'old' 55mm. version. At full aperture it has a decent contrast and an acceptable sharpness. It is at its best at apertures from 1.4 - 5.6. Many photographers are ranking this lens among the best fast lenses in the world! More than 100,000 lenses were made in two versions. As Nico already has an excellent 50mm f/1.2 section where I strongly suggest you to refer at next page for more in-depth reports by him. We will just briefly go through this section on the f/1.2 and concentrate more on the 50mm alternatives.

Nikon's manual focus Nikkor 50mm f/1.2 standard lens a nice rear section picture of a Nikon's manual focus Nikkor 50mm f/1.2 standard lens

" ... The 50mm f/1.2 is the fastest of all Nikkor AI lenses. Although not an AI-s lens, this lens is compatible with any Nikon camera which can accept AI lenses. The only exceptions are the FA, N2000, N2020 and F4, which require the Ai-S mount for compatibility with certain programmed exposure modes...." -Jim-
Credit: Image(s) displayed here are courtesy of Jim Salvas® where his EBAY STORE is one of my favorite spot to look for great images on used photographic equipment. Image(s) copyright © 2006. All rights reserved. Please respect the visual property of the contributing photographer.

A warmth moment at the kindy by Thijs Deschildre
A warmth moment in the kindy...

Credit: Image courtesy of This Deschildre, whose online PORTFOLIO can be accessed at PBase. Image copyright © 2006. All rights reserved. Please respect the visual property of the contributing photographer.


Nikon 50mm Nikkor standard lens with metal lens hood HS-2
As during this stage, Nikon offered a service to help Nikon users to convert their older lenses to Ai-spec, so, if you are not familiar with version history, chances an be high that you may purchase an older Nikkor where it can be difficult to identify if it is an original Ai-Nikkor or an Ai-d (a term invented by Nikon photographers to label those converted non-Ai Nikkor lenses.

The showcased units above of the respective Nikkor 50mm f/1.2, Nikkor 50mm f/1.4, Nikkor 50mm f/1.8 and the Nikkor 50mm f/2.0 (refer below) are all equipped with an Ai-specification. This permits the lenses to couple directly with the various Ai Nikon cameras for fully automatic exposure measurement. Each of them was provide with a meter coupling prong that also enables them to be used with previous series of Non-Ai Nikon SLRs.

a lovely view of a Nikkor 50mm f/1.2 Ai lens A wel taken picture of a Nikon's Nikkor manual focus 50mm f/1.4 standard lens A wel taken picture of a Nikon's Nikkor manual focus 50mm f/1.8 standard lens
Credit: Image at far left above, courtesy of Emanuele@Ebay Store, <or company's URL www.photocamera.com>
Credit: Image courtesy of Mr. Joshua Cohen, whose URL: jcohenphoto.com, as well as his Ebay Store have been my favorite spot. Image(s) Copyright © 2006.

However, minus of what I said earlier, Ai-Nikkor has excellent built quality and its finishes are simply unrivaled Despite later years when Nikon updated their Nikkor lenses into Ai-S to enable newer Nikon SLRs to enjoy multi-modes auto exposure control (such as Program AE and in particularly, the Shutter Priority AE); many users of Nikon FG, Nikon FA or Nikon F301 (1984/5) which incorporated with the said AE faced no issue in operating the Ai Nikkor with these models. Note: however, the lens used MUST still set the aperture to its minimum aperture settings when use them with the Program and Shutter Priority AE. Ai-Nikkor was the first among all Nikkor that followed that incorporated with a secondary aperture scale that enable ADR (aperture direct readout scale) when using the lens with any Ai-spec Nikon model. This faciltatesdirect viewing inside the finder without taking off your concentration on change of aperture on the lens.

Nikon F2a with a Nikon's Nikkor manual focus 50mm f/1.2 standard lens attached

Optical contruction of Nikkor 50mm f/1.2 ai spec
Optical Construction
(PDF File)

Even today, the Nikkor 50mm f/1.2 is still being regarded as the Fastest Lens in the Nikkor Line

* Normal 46° picture coverage.
* Very large maximum aperture. Available light shooting capacity.
* Easy focusing and viewing in dim light.
* Takes 52mm filters the standard for most Nikkor lenses from 20 to 200mm during those days.
* Photographic uses include indoor and outdoor snapshots, landscapes, candid of people, electronic flash photography, travel, full-length portraits in the studio or on location, photojournalism, and available light shooting.

Specifications

Focal length/Aperture:
50mm f/1.2; Lens construction: 7 elements in 6 groups
Picture angle:
46°; Diaphragm: Automatic
Aperture scale:
f/1.2 ~ f/16 on both standard and aperture-direct-readout scale
Exposure measurement:
Via full aperture method; meter coupling ridge provided for Ai cameras and meter coupling shoe for non-AI cameras
Distance scale:
Graduated in meters and feet from 0.5m (1.7 ft) to infinity (oo)
Weight:
390g; Dimensions: 70.5mm dia. x 59mm long (overall); 47.5mm extension from flange
Attachment size:
52mm (P = 0.75); Front lens cap: Snap-On; Lens hood: Snap-On (HS-12), rubber screw-in (HR-2)
Lens case:
CL-34A; No. 61; CP-1; Teleconverter(s): usable with
TC-1 2X(based on Nikon models), TC-200, TC-201S but not advisable.


Credit: Image at left, courtesy of "neekon" (Joe Cabebe) from Hawaii, USA. image appeared herein are Copyright © 2006 of the contributor. All rights reserved.
