Full Specifications - Basic Nikon F2 Camera Body

Type of camera: 35mm single-lens reflex (SLR)
Picture format: 24mm x 36mm (35mm film format)
Lens mount: Nikon bayonet mount
Lenses available
: Nikkor 50mm f/1.4, f/1.8, f/2.0 and 55mm f/1.2 as standard; more than manual focus 80 Nikkor lenses in all

Nikon F2.jpg
Shutter: Horizontal-travel Titanium-foil focal-plane shutter; speeds of from 1 to 1/2000 second and "B" in fourteen steps via shutter-speed dial; intermediate dial settings possible between 1/80 and 1/2000 second (stepless); speeds of from 2 to 10 seconds also available at "B" using self-timer; Time exposure setting also provided.

Viewfinder: Interchangeable Eye Level pentaprism type (model DE-1); virtually 100% frame coverage provided; interchangeable Type A (earlier model) or type K focusing screen supplied as standard
Depth-of-field preview: Button provided; coaxial with mirror lock
Reflex mirror: Automatic instant-return type with Lock-up facility
Flash synchronization: At any speed except "B" and "T" with flashbulbs, and speeds up to 1/80 sec. with electronic flash; built-in hotshoe contact with safety switch provided; threaded sync terminal also provided
FPX sync: automatic switch over with shutter speed selection
Sync range: FP bulbs, all speeds except 1/60 and 1/80 sec.; electronic flash, 1/80 to 1 sec. plus "B "
Self-timer: Can be set for 2 to 10 sec. delay with scale reference graduations of 2, 4, 6, 8 and 10 sec., also serves as timer for 2 to 10 sec. shutter speed range via "B" setting
Film advance lever: Single stroke or a series of strokes; standoff angle 20, winding angle 120
Frame counter: Additive type; automatic resetting

Twin Tower.jpg
Multiple exposure: Via rewind release button
Film rewinding: Crank type; power rewinding using the MD-2 motor drive also possible

<<< --- Twin Tower in Fisheye view... Copyright © images collecton 2000. EEWyn ® Hosted by: Malaysian Internet Resources

Camera back: Hinged; detachable type with memo holder
Ready light: Provided for direct coupling with Nikon electronic flash units
Motor-drive coupling: Provided; Motor Drive Unit MD-2 adaptable without modification
Dimensions (body only) 152.5mm (W) x 98mm (H) x 56mm (D)
Weight (body only): 730g


The Nikon F2 Photomic (With DP-1 Finder)
Note
: Basic F2 body specifications identical with those of Nikon F2

Metering: Through-the-lens center-weighted exposure measurement at full aperture by centering needle; stop-down control possible. Uses Cds cells.

Viewfinder: Interchangeable eye level pentaprism type with built-in TTL exposure meter (F2 Photomic Finder DP-1); virtually 100% frame coverage; exposure data visible in the viewfinder; Type A (earlier model) or Type K focusing screen supplied as standard Exposure information visible in and atop the finder; Electronic flash ready-light provided; data illuminator via accessory.


Metering range
: EV 1 to EV 17 (f/1.4,1 sec. to f/8, 1/2000 sec. with 50mm f/1.4 lens at ASA 100)
Film speed range: ASA 6 to 6400
Maximum aperture setting: f/1.2 to f/5.6
Meter/diaphragm coupling: f/1.2 to f/32
Meter power: by two 1.5V silver oxide batteries
Battery power check: provided; Meter on/off with film advance lever
Dimensions (body only): 152.5mm (6 in.) (W) x 102mm (4 in.) (H) x 65mm (2-9/16 in.) (D)
Weight (body only): 840g (29.6 oz)


Nikon F2S Photomic (With DP-2 Finder)
Note: Basic F2 body specifications identical with those of Nikon F2

Metering: Through-the-lens center-weighted exposure measurement at full aperture with two signal lights; stop-down control possible; it also uses Cds cells with improved metering capability..

Viewfinder: Interchangeable eye level pentaprism type with built-in TTL exposure meter (F2 Photomic Finder DP-2); virtually 100% frame coverage; exposure data visible in the viewfinder; Type K focusing screen supplied as standard Exposure information visible in and atop the finder; Electronic flash ready-light provided Exposure information visible in and atop the finder. EE aperture control attachment contact provided


Metering range
: EV-2 to EV 17 (f/1.4, 8 sec. to f/8, 1/2000 sec. with 50mm f/1.4 lens at ASA 100)
Film speed range: ASA 12 to 6400
Maximum aperture setting: f/1.2 to f/5.6
Meter/diaphragm coupling: f/1.2 to f/32
Meter powered by two 1.5V silver oxide batteries
Battery power: check through signal lights
Meter on/off : via film advance lever
Dimensions (body only): 152.5mm (6 in.) (H) x 110mm (4-11/32 in.) (W) x 65mm (2-9/16 in.) (D)
Weight (body only): 880g (31.0 oz)


The Nikon F2SB Photomic (With DP-3 Finder)
Note: Basic F2 body specifications identical with those of Nikon F2

Viewfinder: Interchangeable eyelevel pentaprism type with built-in TTL exposure meter (F2SB Photomic Finder DP-3); virtually 100% frame coverage; exposure data visible in the viewfinder; type K focusing screen supplied as standard; eyepiece shutter built-in.

Nikon F2SB.jpg
Exposure metering: Through-the-lens (TTL), center-weighted full-aperture measurement employing two silicon blue-diodes (SBC); LED display indicates five exposure gradations through combinations of three symbols (+ O - ); when eyepiece shutter is closed, correct exposure is indicated on top of finder; meter cross coupled with both diaphragm and shutter speed controls;

ASA range 12 - 6400; metering range EV minus 2 - EV 17 (i.e.,f/1.4 at 8 sec., f/8 at 1/2000 sec.) with 50mm f/1.4 lens at ASA 100; Non-AI metering coupling method; aperture coupling range f/1.2 - f/32; shutter speed coupling range 10 - 1/2000 sec.; meter powered by two 1.5V silver oxide batteries; meter on/off with film advance lever; data illuminator built-in; EE aperture control attachment contact provided

Battery power checker: Provided with illuminator switch
Dimensions (body only): 152.5mm (W) x 102mm (H) x 66mm (D)
Weight (body only): 840g




The Nikon F2A Photomic
(With DP-11 Finder)
Note
: Basic F2 body specifications identical with those of Nikon F2

Viewfinder: Interchangeable eye level pentaprism type with built-in TTL exposure meter (F2A Photomic Finder DP-11); virtually 100% frame coverage; exposure data visible in the viewfinder; type K focusing screen supplied as standard

Nikon F2 A.jpg
Exposure metering: Through-the-lens (TTL), center-weighted full-aperture measurement employing two Cds cells; exposure correctly set by adjusting aperture-and/or shutter speed for meter needle centering; ASA range 6 - 6400; metering range EV-1 - EV-17 (i.e., f/1.4 at 1 sec., f/8 at 1/2000 sec.) with 50mm f/1.4 lens at ASA 100;

The built-in diaphragm/meter coupling lever for Nikkor lenses capable of automatic maximum aperture indexing (Al); the aperture coupling range f/1.2 - f/32; powered by two 1.5V silver-oxide batteries; meter on/off with film advance lever; external meter indicator also provided; data illuminator via accessory.


Battery power checker: Provided
Dimensions (body only): 152.5mm (W) x 102mm (H) x 65.5mm (D)
Weight (body only): 880g


<<<<<<<--------Nepal. (Jpeg File 103k) Copyright © images collecton 2000. MCLau ® Hosted by: Malaysian Internet Resources

The Nikon F2AS Photomic (With DP-12 Finder)
Note: Basic F2 body specifications identical with those of Nikon F2

Viewfinder: Interchangeable eyelevel pentaprism type with built-in TTL exposure meter (F2AS Photomic Finder DP-12); virtually 100% frame coverage; exposure data visible in the viewfinder; type K focusing screen supplied as standard; eyepiece shutter built-in

Nikon F2AS.jpg
Exposure metering: Through-the-lens (TTL), center-weighted full-aperture measurement employing two Silicon Photo-diodes (SPD); LED display indicates five exposure gradations through combinations of three symbols (+ O - ); when eyepiece shutter is closed, correct exposure is indicated on top of finder; meter cross coupled with both diaphragm and shutter speed controls

ASA range 12 - 6400; metering range EV minus 2 - EV 17 (i.e.,f/1.4 at 8 sec., f/8.0 at 1/2000 sec.) with 50mm f/1.4 lens at ASA 100; built-in diaphragm/meter coupling lever for Nikkor lenses capable of automatic maximum aperture indexing (AI); The aperture coupling range f/1.2 - f/32; shutter speed coupling range 10 - 1/2000 sec.; meter powered by two 1.5V silver oxide batteries; meter on/off with film advance lever; data illuminator built-in; EE aperture control attachment contact provided

Battery power checker: Provided with illuminator switch
Dimensions (body only): 152.5mm (W) x 102mm (H) x 66mm (D)
Weight (body only): 840g


<<< ----BackStage, Chinese Opera. Copyright © images collecton 2000. Arthur Teng ® Hosted by: Malaysian Internet Resources
