cont.
Canon EF 75-300mm f/4~5.6 MK II, 1995
Canon EF 75-300mm f/4~5.6 (USM) MK II Telephoto Zoom Lens Marketed: 1995, Discontinued: 1999

Along with a few other well-spec "budget" wideangle zoom that were sold very well in numbers, Canon also saw the commercial potential of this Tele-zoom and updated the lens
in both standard MM and USM versions in 1995. Generally, the market during this time was the beginning of a long prime period of Canon with its clear dominance at the professional user's market with the hugely successful Canon EOS-1N series. Overall, the Canon EOS system has matured both in cameras as well as in the EL lens lineup. The update was essentially part of a broad scale lens updating program during the mid of '90.

Credit: Image courtesy of Laura Kornylak ® <shutterblade@comcast.net> from shutterblade*com where the Company has a website on its own. Image copyright © 2003. All rights reserved. Please respect the visual property of the contributing photographer.

In fact, other than a golden-line USM ringed around mid section to seperate the two, BOTH the lenses shared a common update. During its launched, some equipment reviewers did asked about the EF 75-300mm f/4-5.6II USM in a Q & A session: Q: Compared to the EF 75-300mm f/4-5.6 USM, what improvements have been made to the EF 75-300mm f/4-5.611 USM? Canon spokesman oulined as:. - The exterior sports a silky finish to give a high-quality look. The zoom-ring ring rubber covering is finer, making it easier to grip and giving the lens a high quality look. Other design-related details have been improved. The internal mechanical construction and electrical circuits have been improved. However, optically both lenses remained unchanged, retaining the optical formula as 13 elements in 9 groups formation.

Scenary @ Bessastair by Pall Gudjonsson from ICELAND
Bessastadir..

Credit: Image courtesy of PALL Gudjonsson from Iceland. whose PORTFOLIO can be accessed at PBase. Image copyright © 2006. All rights reserved. Please respect the visual property of the contributing photographer.

The debut of these two lenses timed themselves at a time which we witnessed some brilliance of Canon EF lenses being introduced at almost the same time (such as the Canon EF 70-200mm f/2.8L USM) but the lens that caught the entire community in 1995 was caught by introduction of the first zoom lens that incorporated with an innovative Image staberlizer technology. Rather surprisingly, Canon has chosen its immesensly popular 75-300mm as its first trial. The resulting product, Canon EF 75-300mm f/4~5.6 II IS USM as it was called, stole the limelight and thus, there are actually three versions of the Canon EF 75-300 tele-zoom lens in the EF lens family at this period.

lens mount section of Canon EF 75-300mm f/4.5~5.6 tele-zoom lense Loading ...... Canon  EF 75-300mm f4-5.6 II USM Version 60K loading ...
Although not as beutifully done as with the Canon luxulous, professional oriented L-series family, the overall built quality of the two lenses is above average. The rear metal lens mount is a rare treat found among all the entry level budget zoom lenses flooding in the market today.

Credit: Image courtesy of Creation House @EBAY®, Image(s) copyright © 2005. All rights reserved.

Three versions of Canon EF 75-300mm f/4.5~5.6 tele-zoom lense Loading ......
The Product Concept is basically improved the Canon products with a strategically priced tele-zoom as other rivaling manufacturing Companies which includes the third party labels also realized its popularity. The key to add value is via improved high-quality external appearance based on a new design which includes a smoother, silky surface finish as well as a new pattern zoom ring. The performance comparison between the identical lenses between EF 75-300mm f/4-5.611 USM and EF 75-300mm f/4-5.6 II shares a common optical design but the latter uses a DC motor to drive the autofocus. Since it uses a rubber belt to suppress the noise level, the AF noise is only slightly higher than the EF 75-300mm f/4-5.6 II USM's. The DC motor alternative was retained in the EF lens family was aimed to make the lens more affordable to more people (or fencing off threats from third party label lenses).

Comparison of specifications with other lenses:-
    Canon EF75-300mm f/4.0~5.6 II USM Canon EF75-300mm f/4.0~5.6 II Sigma 75-300mm f/4.0~5.6 DL-ZEN Minolta EF75-300mm f/4.5~5.6   Nikon Nikon AF Nikkor 70-300mm f/4-5.6D ED *
Optical construction (groups/elements)   13 elements 9 groups 13 elements 9 groups 14 elements 11 groups 13 elements 11 groups   13 elements 9 groups
Overall length   122.1 mm 122.1 mm 119.5 mm 122mm   117mm
Maximum diameter   71 mm 71 mm 74 mm 72.5 mm   74mm
Filter diameter   58mm 58mm 55mm 55mm   62mm
Weight   495g 495g 565g 530g   520g
Closest focusing   1.5m 1.5m 1.5m 1.5m   1.5m
diaphragm   7 7 no info no info   9

* Note: The Nikon 70-300mm f/4-5.6D ED seemingly has a good spec but rumored to have been contracted to produced for Nikon by Tamron but nobody bothers anyway ..

Flowery picture  by Messara Messara from CANADA
Flowery..

Credit: Image courtesy of Messara Messara from Canada. whose PORTFOLIO can be accessed at PBase. Image copyright © 2006. All rights reserved. Please respect the visual property of the contributing photographer.

Front lens element of Canon EF 75-300mm f/4.5~5.6 MK II USM tele-zoom lense Loading ...... Rear lens mount of Canon EF 75-300mm f/4.5~5.6 MK II USM tele-zoom lense Loading ......
Front and rear view of the revised Canon EF 75-300mm f/4~5.6 II USM version

Credit: Image courtesy of Creation House @EBAY®, Image(s) copyright © 2005. All rights reserved.

Technical Specification for Canon EF 75-300mm f/4-5.6 II USM Telephoto Zoom lens: -

Type: - Autofocus lens type with manual focusing mechanism
Focal Length: Variable focal length from 75-300mm

Focus Adjustment:- Autofocus ; single zoom range with manual focusing ring design
Manual Focusing:- possible via AF/M switch;
Zoom Adjustment
:- via zoom ring rotating type; indicative zoom settings: 75mm, 100mm, 135mm, 200mm, 300mm
Closest Focusing Distance:- 1.5m (4.9ft); Maximum Magnification:- 0.25X @300mm; MACRO setting indicated
Distance Scales: Nil; Drive System:- Micro-USM; FTM may not be possible

Original lens hood Canon ET-60
Angle of View:- 27°~6°50' / 18° 11'~4° 35' / 32° 11'~8° 15'; Aperture range:- f/4.0 - f/32/f45
Number of Diaphragm Blades: - 7 blades; Minimum Aperture: - f/32~f/45
Filter rotation: YES; Filter Attachment Size:- 58mm front mounting; Lens construction:- 13 Elements in 9 Groups
Extenders: Usable but not advisable.
Others: - Extension Tube EF25 (II) 0.39X-0.09X ; EF25 0.31X ~0.04X
Diameter:- 122.1mm x 71mm (4.8" x 2.8");
Weight:- 495g (1.1 Ib)

Optical Contruction of original version MTF for Canon 75-300mm f4~5.6 tele zoom
Accessories:- Lens Cap/pouch E-58U; lens hard case: LH-C16 (possible); lens Hood:- ET-60; Soft Case:- ES-C17; Gelatin Holder III: (5); Holder IV: (4); Other Canon general filters and macro accessories.

Status:
Discontinued.

Seperator line
Foggy morning @ Loveland, Colorado, USA
Technical Specification for Canon EF 75-300mm f/4-5.6 II Telephoto Zoom lens: -

Type: - Autofocus lens type with manual focusing mechanism; Front group rotating extension system with micro motor
Focal Length: Variable focal length from 75-300mm
Focus Adjustment:- Autofocus belt driven, using micro-motor; single zoom range design
Manual Focusing:- possible via AF/M switch
Zoom Adjustment:- via zoom ring rotating type; indicative zoom settings: 75mm, 100mm, 135mm, 200mm, 300mm

Foggy morning @ Loveland, Colorado, USA..

Credit: Image courtesy of Charles Jones from COLORADO
United States,
whose PORTFOLIO can be accessed at for a wide topics. Image copyright © 2006. All rights reserved. Please respect the visual property of the contributing photographer.

Canon  EF 75-300mm f4-5.6 II Version 38K loading ... Canon EF 75-300mm f/4.5~5.6 MK II tele-zoom lense Loading ......
Closest Focusing Distance:- 1.5m (4.9ft); Maximum Magnification:- 0.25X @300mm; MACRO setting indicated
Drive System:- Front group rotating extension system with micro motor
Distance Scales: Nil


<<<--- Front and rear view of the revised Canon EF 75-300mm f/4~5.6 MK II version

Credit: Image courtesy of Creation House @EBAY®, Image(s) copyright © 2005. All rights reserved.

Angle of View:- 27°~6°50' / 18° 11'~4° 35' / 32° 11'~8° 15'; Aperture range:- f/4.0 - f/32
Number of Diaphragm Blades: - 8 blades; Diaphragm:
Electromagnetic (EMD); Minimum Aperture: - f/32~f/45
Filter rotation: YES; Filter Attachment Size:- 58mm front mounting; Lens construction:- 13 Elements in 9 Groups
Extenders: Usable but not advisable. Others: - Extension Tube EF25 (II) 0.39X-0.09X ; EF25 0.31X ~0.04X
Diameter:- 122.1mm x 71mm (4.8" x 2.8"); Weight:- 480g (1.1 Ib)
Optical Contruction of Canon tele zoom 75-300mm MTF for Canon 75-300mm f4~5.6 tele zoom
Accessories:- Lens Cap/pouch E-58; lens hard case: LH-C16 (possible); lens Hood:- ET-60; Soft Case:- ES-C17; Gelatin Holder III: (5); Holder IV: (4); Other Canon general filters and macro accessories.

Status:
Discontinued.


Seperator line

Previous | NEXT | 2/6 The IS (Image Stabilizer Version of the Canon EF75-300mm f/4~5.6 II (USM)
