Canon EOS-1N (1994) Credit: Image(s) courtesy of 'Shutterblade team' (e-mail)who specializes trading of new, used collectable cameras. The Company also operates a popular Ebay Store. All image(s) appeared herein are Copyright © 2005. All rights reserved. Please respect the visual property of the contributing photographer.		Canon EOS-1 (1989) Credit: Images courtesy of Adorama® Inc. "Ebay - Mathew Duren" <ebay@adorama> Website URL: Adorama.com, who also operates a popular Ebay Store. All images appeared herein are Copyright © 2003. All rights reserved. Please respect the visual properties of the contributing photographers.

Category	Intra-Company Products Comparison =Superior/Excellent = Not provided, not possible or less responsive	Camera Models
		Canon EOS-1N	Canon EOS-1
Focusing: Manual / Auto focusing	AF focusing area (points)	| | + | | (5 across)	+ (single, at center)
	Focusing point selection
	AF working range	0 ~ 18	1 ~ 18
	LED / Beeper sound alert	/	/

Viewfinder	Built-in Diopter
	Magnification (50mm / OO)		0.72	0.72
	Eyepoint		20mm	20mm
	Indications		Digital full indication	Digital full indication
	Interchangeable screens (types)		x 8 (Ec-CII)	x 8 (Ec)
	Depth of field check	Manually Set
		Calculated
	Built-in diopter adjustment function
	Built-in eyepiece shutter
	Superimposed display		LED
Metering Systems	Number of evaluative metering zones		16	6
	Partial metering
	Fine Spot metering
	Spot metering photometry: Linked to focusing points		/	/
	Center-weighted average metering
	Metering range (EV ISO100, at normal temperature)	Evaluative	0~20	0~20
		Partial	0~20	0~20
		Fine Spot	3~20	2~20
	ISO film speed (Applicable to DX)		6~6400	6~6400

Exposure Control	Shutter-priority AE
	Aperture-Priority AE
	Depth-of field AE
	Intelligent Program/M-shift		/	/
	Manual
	Flash A-TTL / TTL		/	/
	TTL automatic flash exposure + multi segment flash meter zone(s)		x 3 zones
	TV and AV input	1/3 f-stop
		1/2 f-stop	CF
		1 f-stop	CF	CF
	Exposure Compensation	AEB
		Manual
	Exposure Compensation Steps	1/3 f-stop
		1/2 f-stop	CF
	AE lock A/M		/	/
	Flash exposure compensation
	Flash out of range warning		v
	Mirror lock up		CF
	Multiple exposures (Preset)
Construction	Materials		industrial grade carbon fibre reinforced polycarbonated	reinforced Polycarbonated
	Modular (with options to assemble or custom set up) *

Shutter	Materials		Carbon fibre +super duralumin	dual bladed super duralumin
	Curtain Speed (vertical)		2.7 ms/24mm)	no info
	Speed Range (sec.)		1/8000~30sec	1/8000~30sec
	X-Sync Time (sec.)		1/250	1/250
	Reliability (min. lab tested exposure cycle)		100,000	50,000
Film Transport (24 exp.)	Quiet Film Transport		4DdB	x 70 dB
	MD Functions (fps) Booster Drive E1	S
		CH	6.0 fps	5.5 fps
		CL	3.0 fps	3.0 fps
		C	3.0 fps	2.5 fps
	Rewinding speed (sec.)		5.0 sec	8.0 sec
	Mid Roll rewinding
	Shooting capacity	Normal temperature (rolls)	75	75 /100 (45)
		Low temperature (rolls)	30 (PDB-E1) KR15/51	12 /6 (30)

Power supply	Main power source (Basic Body)	2 x CR5	2 x CR5
	Memory backup		CR1220 x 1
	MD (PDB-E1)	8 x LR6	8 x LR6
	Type-AA battery pack (PB-E1)	4 x LR6	4 x LR6
PC terminal
External display / main input method		LCD / with electronic Dial	LCD / with electronic Dial
Custom functions & number of types		14	8
Remote control terminal
Dimensions (mm)	W	161	161
	H	112.1	106.6
	D	71.8	71.8
Weight (g) Excluding Batteries		855g	850g
Others	Custome Functions (numbers)	x 14	x 8
	Side Box (pam Door material)	Leather pattern molding + Rubber Coating	Leather tone coating
	Memory Back-up Battery	Not required	CR1220 x 1
	Mirror lock up	via CF
Year introduced /release date		Oct. 1994	Oct. 1989
