Canon high performance AF TTL Speedlite 540EZ Up to the period of EOS-1N era, the Canon Speedlite 540EZ was easily one of the most sophisticated flash ever designed by Canon. Full-featured, clip-on flash unit with an AF-assist beam linkable to any of the five focusing points. Powerful output with a guide no. of 16 to 54 m, or 52 to 177 ft, at ISO 100. Flash coverage with an ultra-wide-angle of 18mm to 105mm.
Canon AF Sppedlite 540EZ
Connectable to external power packs. For a detailed description on this high-tech flash model, I think it should deserve a separate section to highlight all its various functions, capabilities and compatibility issue with other Canon SLR camera models. Click here to the

| Dedicated site for Canon Speedlite 540EZ |
Credit: Image courtesy of Mr. Elle of www. PhoneBusta. co.uk®, U.K.. PhoneBustas also manages an Ebay Store too; both of them trade many photo equipment of various labels. Image(s) copyright © 2005. All rights reserved.

Flash at the seasideby Andre_Antunes (80k Jpeg) Loading ...
Flash at the seaside ..

Credit
: Image courtesy of Andre Antunes from Portugal whose PORTFOLIO can be accessed at PBase. Image copyright © 2006. All rights reserved. Please respect the visual property of the contributing photographer.

Nomancluture Canon 540EZ Front section   Nomancluture Canon 540EZ Rear sectionCredit: Nomenclature / Main Reference Map of a typical EZ AF TTL Speedlite constructed based on two original images contributed by "Gold Silence®" from his Ebay Store Image(s) copyright © 2005. All rights reserved. Please respect the visual property of the contributing photographer.

* Type: Direct-coupling clip-on type A-TTL/TTL automatic flash with AF auxiliary light (compatible with 5 focusing points when used with EOS 1N), A-TTL preflash, auto zoom, and bounce functions.
* Auto Zoom:   Zoom position is automatically set according to focal length data received for the lens when the shutter button is pressed halfway (SW-1 ON).
* Manual Zoom:   Zoom position changes sequentially according to manual operation of a push button located on the flash unit.
* Wide-angle diffusion panel:   When the wide panel is manually pulled into place, the flash automatically zooms to the 28mm position to provide a coverage and angle equivalent to an 18mm lens.
* Zoom Stop Positions:   24mm, 28mm, 35mm, 50mm, 70mm, 80mm, and 105mm (During bounce flash photography when the flash unit is set for auto zoom, the zoom position is automatically set to 50mm).
* Zoom Speed:   Approx. 0.8 sec (at normal temperature).
* Dimensions (W x H x D):   3-1/8" x 5-7/16" x 4-7/16" (80 x 138 x 112 mm).
* Weight:   14oz./405g (without batteries).


Function Map for Major components Canon 540EZ flash.
IF you are lazy to go through various details of the Canon AF TTL 540EZ separate website, this illustration is the summary of its functions on various settings, switch and buttons found on the flash.

Credit: The illustration was based on an original image contributed by Mr. Elle of www. PhoneBusta. co.uk®, U.K.. PhoneBustas also manages an Ebay Store too; both of them trade many photo equipment of various labels. Image(s) copyright © 2005. All rights reserved.

Canon Speedlite 480EG

This unusual shape, bracket/grip-type flash unit boasting a high, maximum guide no. of 48 (m), or 158 (ft.), at ISO 100. Wide- and tele-panels provide flash coverage angles for 20mm and 135 mm focal lengths respectively. Connecting it to a Ni-Cd Pack TP reduces the recycle time to 0.2 to 6 sec. which makes It a perfect companion flash for who who is seeking a powerful flash for repeating flash photography (come to think of it, the circular flash tubes reminds me of the Nikon Repeating flash SB-6 of the '70). The 480EG also accepts separately purchased Battery Pack E. Even in used condition, I have seen this bracket handle flash sold for approx. USD500-00. With a maximum guide number of 68/223 (ISO 100 m/ft), the 480EG is Canon's most powerful grip-style electronic flash. Its wide range of exposure control options, as well as its unique clamp-and-bracket design, emphasize durability and simple operation. The only complain you can pick on it is, it is quite heavy (weighs 1,065g even without batteries installed inside). But for works that demands the most powerful and dependable artificial illumination, here is one that you can count on.

The TTL 480EG System was designed to meet requirement of professional photographers who may require powerful, fast recycling speed in demanding night photo sessions. This large, rugged flash with a bracket and a hand grip offers powerful light output of guide number 160 @ ISO 100, ft.. Another trademarks is its short recycling time and versatility to work in many situations. It can offer TTL automatic exposure control with AF-EOS and even older MF camera such as T90 via the TTL Shoe Cord E; the built-in sensor can also provide auto flash control with any Canon (or even other camera labels) that equipped with PC socket/terminal via Synchro Cord 480. Manual flash exposure control can be set by 3 stages settings - full, 1/4 and 1/16X reduction. The 480EG has an unusual twin flash tubes in a circular reflector which was designed to provide uniform light distribution across up to picture angle of a 20mm ultrawide. It is a heavy-duty, durable constructed unit and come with a higher price tag than most conventional shoe-mount Canon flash. Rapid recycling and great versatility to work in or outdoor.

Canon 480EG High performance speedlite
" ... Canon EOS 480EG speedlight flash unit. It is in excellent condition, with only a little wear. Compatible with Canon EOS Rebel series, Elan series, 600 series, etc.  This flash has a bounce head for natural and professional flash lighting techniques. The guide number is approximately 223ft with 100 ASA film. It operates as an E-TTL flash giving the most accurate exposures working with metering system in your Canon EOS camera. This would be a great flash to add to your Canon EOS camera system! Includes a CZ Quantum power cord..."


Rear section of Canon 480EG Top panel control for Canon 480EG

Credit: Image(s) courtesy of 'Shutterblade team' (e-mail)who specializes trading of new, used collectable cameras. The Company also operates a popular Ebay Store. All image(s) appeared herein are Copyright © 2005. All rights reserved. Please respect the visual property of the contributing photographer.

The Canon 480EG offers TTL flash exposure with EOS models and even with the older Canon T90 as it has an external sensor for use with earlier Canon models (via TTL automatic flash is obtained by using TTL Shoe Cord E to connect the 480EG to the accessory shoe of an EOS or T90 camera). This Canon 480EG is only available in some markets. Below are a few dedicated accessories which were designed to expand capabilities of the flash to greater height.

Canon 480EG setup

Slave unit for 480EG

Panel Adptor for 480EG

Tele_panel

Wide Panel for 480EG

Slave Unit E Plugs into the Speedlite 480EG to make it fire remotely in response to the light from another flashgun.

Panel Adaptor Used to attach the Wide and Tele Panels to the head of the Speedlite 480EG.

Tele Panel Attaches to the Speedlite 48OLG to increase the power of the flash when used with lenses of 135mm and greater.

Wide Panel Attaches to the Speedlite 480EG to increase the coverage of the flash to suit lense a down to 20mm.


* Type: Grip-style TTL automatic, external sensor-based automatic and manual flash (with bounce function).
* Attachment   Via TTL Shoe Cord E, Synchro Cord 480 or with optional slave unit as off-camera cordless light source.
* Guide Number   160 (ISO 100, ft. @ 35mm coverage angle).
* Flash Coverage   20mm-135mm (via its supplied wide and tele panels).
* Number of Flashes   Alkaline-Manganese batteries: 100 to 700 Ni-Cd Battery Pack: 90 to 600
* Recycling Time   With Alkaline-Manganese batteries: 0.2 to 17 sec. With Ni-Cd Battery Pack: 0.2 to 6 sec.
* Flash Duration   1/850 sec. to 1/20,000 sec.
Synchronization   First curtain, X-Sync.
*Flash Control System   TTL automatic control by metering light reflected from the film plane (with TTL Shoe Cord E connection); External sensor auto flash control (with Synchro Cord 480); Variable-power Manual.
*Flash Coupling Range   TTL auto flash; 2.4-104.9 ft. (with 50mm f/1.4 @ ISO 100)
*General Power Source   With Transistor Pack E: Six size-C LR14 alkaline-manganese (Battery Magazine TP) or NR-SC Ni-Cd (sealed Ni-Cd Pack TP) batteries.
*Color Temperature   Same as Daylight
*Dimensions   Main Unit: 3-7/8 x 10-1/16 x 4-1/2 in. (98 x 256.5 x 114.3mm); With clamp and bracket: 11-7/16 x 10-1/16 x 4-1/2 (291 x 256.5 x 114.3mm)
* Weight:   Main unit: 25.03oz. (715g) without batteries; With clamp and bracket: 37.03oz. (1,065g) without batteries

Off-Camera Shoe Cord 2 Allows a dedicated Speedlite to be used off camera with all the automatic features intact. Great for varying the lighting angle for close subjects. Extends up to 60 cm (2 ft).
Canon Off-Camera Shoe Cord 2
This Canon accessory allows you to connect your Canon Speedlite on one end of the cord and the other end will be mounted to the Hot Shoe unit of your EOS camera. You can stretch the accessory's cord by up to 0.6 metres long and away from the camera in any shooting degrees you wish to point the flash towards your intended subject. Except for EOS 630 and the pellicle mirrored-equipped Canon EOS RT, this Off camera Shoe Cord 2 works with virtually all the current EOS cameras Good thing is, it is an affordable , dedicated accessory, handy for achieving off-camera flash photography without the harsh shadows behind your subjects common when using direct flash exposures. Note: When you are using the TTL Hot Shoe Adaptor 2 with the Off-Camera Shoe Adaptor, A-TTL is not possible and it will revert to normal TTL.

The Off Camera Shoe Cord 2 unit also come with a built-in tripod socket at the other end where the Speedlite unit is attached to which permits it to be locked onto a tripod and frees your hand from holding the off-camera flash. Please take note: All the external power sources of the 540EZ are used in common with the 430EZ. The flash sync shutter speed and the availability / unavailability of an out-of-coupling-range warning when using A-TTL preflash are different depending on the model.

Canon Battery Pack E Canon Transistor Pack E Set
Compact Battery Pack E Compact external power pack. Usable with many EOS camera models. When used with the 540EZ's internal batteries, in particularly, it reduces the recycling time to 0.2 to 5 sec. Uses six size-AA alkaline or Ni-Cd batteries.

Transistor Pack E Set External power pack available for two types of size C batteries: Dry cells and Ni-Cd The dry cell set includes Battery Magazine TP and Connecting Cord ET. The Ni-Cd set includes Ni-Cd Pack TP, Ni-Cd Charger TP, and Connecting Cord ET.

NOTE:The current (2005) Battery Pack CP-E3 is designed for exclusive use with Speedlites. 580EX, 550EX but also USABLE with 540EZ, 430EZ, MR-14EX and MT-24EX. Accepts 8 AA Alkaline, Ni-Cd, Ni-MH or lithium batteries.

If you have a Canon 580ex, 550EX, 540EZ or 430EZ flash and need faster, longer lasting flash performance, the Compact Battery Pack CP-E3, will definitely help to provide that. The thin and compact unit accommodates eight AA sized batteries and when connected provides the extra power needed to enable faster recycle times for a longer period of time, than when just using the basic flash unit alone. Its recycling times is approx. 1.7 second, excellent for an extended shooting period. Using Ni-MH type rechargeable batteries, probably provides a maximum performance in this combination.

Sizes/Dimension of various Canon External Power Sources (approx. figures):-
Laminated Pack E
1. Dimensions Laminated pack itself: 75 (W) x 194 (H) X 40.8 (D) mm / 2-15/16 (W) x 7-5/8 (H) x 1-5/8 (D) in When housed in a case: 87(W)x2l4(H)x58,(D)mm 3-7/16(W) x 8-7/16(H) x 2-1/4(D)in (external dimensions of the case) 2. Weight When the case, strap and connecting cord are included but the battery is excluded: 415 g / 14.5 oz; When the laminated battery is included in the actual use state: 915 g / 32 oz
Transistor Pack E 1. Dimensions Transistor pack itself: 91 (W) x 194 (H) x 34.5 (D) mm / 3-9/16 (W) X 7-5/8 (H) x 1-3/8 (D) 'in When housed in a case: 102 (W) x 200 (H) x 55 (D) min / 4-1/16 (W) x 7-7/8 (H) x 2-3/16 (D) in (external dimensions of the case); 2. Weight:- When the case, strap and connecting cord are included but the battery is excluded: 460 g / 16.1 oz; When the battery magazine TP is included in the practical use status: 960 g / 33.6 oz; When the Ni-Cd pack TP is included in the actual use state:-845 g / 42.3 oz; Weight of battery magazine itself: 70 g / 2.5 oz (Weight of each LR 14 battery: 71.5 g / 2.5 oz)
Compact Battery Pack E 1. Dimensions Compact battery pack E itself: 69(W) x l58(H) x 25(D)mm/2-11/16 (W ) x 6-1/4(H) x l5/16 (D ) inches. When house in a case: 78 (W) x 168 (H) x 41 (D) mm / 3-1/16 (W) x 6-5/8 (H) x 1-5/8 (D) in (external dimensions of the case) 2. Weight When the case, strap and main unit are included but the batteries and tripod screw are excluded: 155 g / 5.4 oz; When the batteries are included in the actual use state: 305 g /10.7 oz
Ni-Cd charger 1. Dimensions 47 (W) x 42.5 (H) x 65 (D) mm / 1-7/8 (W) x 1-11/16 (H) x 2-9/16 (D) in 2. Weight 180 g / 6.3 oz


Multiple Flash System Enables multiple flash units to be used with TTL auto flash metering. Up to four Speedlites. can be set up. The maximum extension length is 9m/29.5 ft.

The Canon multiple flash accessories allow you to use up to four (4) flash units for one exposure. Either TTL flash auto exposure or manual control can be used, giving the flexibility needed to handle almost any lighting situation that requires artificial illumination. Controlled lighting effects can be obtained by varying the distances of the Speedlites. from the subject. A basic two light portrait that set up can be obtained, for example, by positioning the first Speedlite to one side as the main light. with fill in illumination from the second Speedlite used from the front, but further away than the main Speedlite. Multiple flash set ups are especially useful for still life and close up photography where additional Speedlites. can be used for backlighting or for illuminating tire background. Results rivaling those produced with professional studio equivalent are possible.

<< -- This system is configured using five multiple flash accessories: (1) TTL Hot Shoe Adopter 3. (2) TTL Distributor, (9) Off camera Shoe Adapter. (4) Connecting Cord 60. (5) Connecting Cord 300. Automatic TTL flash exposure control is possible using up to four Speedlites. selected from the EOS dedicated Speedlites., the Speedlite 300TL and the Macro Ring Lite ML 3.

Canon TTL Hot Shoe Adapter 3 Canon TTL Distributor
TTL Hot Shoe Adapter 3 Placed in the EOS camera's accessory shoe, this device controls up to 4 off-camera Speedlites. TTL Distributor System connector, accepts up to 4 connecting cords. Used for multiple TTL flash setups with EOS cameras and Canon AF Speedlites. Requires shoes and cables

Off-Camera Shoe Adapter
Off-Camera Shoe Adapter (part number CZ2-1453) Off-camera Speedlites. are placed in this accessory, which accepts one connecting cord.

Canon Connecting Cord 300

Canon Connecting Cord 60


Connecting Cord 300 3 m/9.8 ft. straight cord, with connections on both ends. Attaches to Canon OA-2 and Off Camera Shoe Adapter 3. Great for doing multiple flash set ups. Connecting Cord 60 60 cm/2 ft. coiled cord, with connections on both ends. * Coiled 2 foot Cord. It can connects to TTL Shoe Adapter 2, TTL Distributor, or Off Camera Shoe Adapter,

Others accessories for Canon 540EZ unit:- :Soft case for 540EZ main unit; Case for compact battery pack E; Connecting cord for laminated pack E; Case for laminated pack E; Strap for laminated pack E315; Connecting cord for transistor pack E; Case for transistor pack E; Strap for transistor pack E; Battery magazine TP for transistor pack E; Ni-Cd pack TP for transistor pack E; Ni-Cd charger TP for transistor pack E
