Modern Classic SLR Series :
Additional Information on Canon EF lenses
Canon EF 200mm f/2.8
L USM (Original & MK II versions) Telephoto lens

File size: 68k HTML Loading...

cont ...
Canonmatic R 200mm f/3.5
Background and Version History During the FD days, Canon used to have a fantastic telephoto helicoid focusing lens, Canon FDn 200mm f/2.8 which deploys with an internal focusing system; it takes lovely portraits and has a rigid, extremely well made construction. Optically, the impressive FDn has a straight forward, 7 elements in 6 group design as compared to the older version, Canon FD S.S.C. which uses 5 elements in an even more simpler 5 groups formula. It was a favorite for many Canon photographers those days because the best tele-zoom available was only the moderately speed FDn 80-200mm f/4.0L (other than a slower lens speed equivalent in the 200f/4).

<<<--- An aged Canonmatic-R 200mm f/3.5 telephoto lens Credit: Images courtesy of UseLEVIs@Ebay® where this image was spotted on his EBAY Store. Image(s) copyright © 2006. All rights reserved. Please respect the visual property of the contributing photographer.

Beach Front -  by timothy _bateman (61k Jpeg) Loading ...
Beach Front ..

Credit
: Image courtesy of Timothy Bateman from U.K. whose PORTFOLIO can be accessed at PBase. Image copyright © 2006. All rights reserved. Please respect the visual property of the contributing photographer.

Canon FDn 200mm f/2.8 Newer version FD 200mm f/2.8 SSC older version
Older Canon's FD mount lenses are engineered to cause little wear on the mounting surfaces, the chrome ring bayonet (FD S.S.C.) was considered by some far superior in mechanical quality to later FD mount bayonets (later Canon FD mount bayonets were redesigned such that all moving parts are contained within the lens barrel. All FD mount lenses are compatible with all FD mount cameras). But I would think it is more like a personal opinion and I would think both have not much of a difference between the new and old.

The early days of Canon EF lens family didn't has a similar fixed focal length lens type in the 200mm category. Reasons being Canon had SEVEN EF zoom which had the 200mm focal length covered (EF 50-200mm f/3.5~4.5 AFD; EF 50-200mm f/3.5~4.5L AFD; EF 70-210mm f/4.0 AFD; EF 80-200mm f/2.8L AFD; EF 100-200mm f/4.5A; EF 100-300mm f/5.6 & EF 100-300mm f/5.6L). In particular, the professional class L-series EF 80-200mm f/2.8L also posted a similar fast lens speed of f/2.8 with the added benefit of providing the convenient in multiple manipulation of varying focal lengths. So, the development of a prime focal length of a fast speed 200mm was only realized in 1991.


Canon Original EF 200mm f/2.8L USM Telephoto Lens
Marketed: 1991, Discontinued: 1996

Part I:- The first version of the Canon EF 200mm f/2.8L USM is a high-quality, large-aperture telephoto lens featuring the good feature in light weight and a compact size for superior handling and mobility. The lense has two UD glass elements to suppress axial chromatic aberration. Similarly to the FD version, but a newly-designed rear focusing system was deployed in compensating for the changes in spherical aberration during focusing which occurs in the conventional rear focus design.

Canon  EF 200mm f/2.8L Original Version 38K loading ...
Overall, Canon was confident that the image quality has improved considerably from its FD predecessor, especially at near and medium distances, and offers very high level of contrast and sharpness throughout the entire range even begin from the closest focusing distance of 1.5 m/4.9ft all the way to infinity. A telephoto lens can be a good entry into a whole new world of photographic opportunities in the fields like nature, wildlife, sports, news/journalist, portraiture or even leisure photography on close-up topics.

Due to its possible wide applications of this lense by photographers, a built-in Ultrasonic Motor (USM) is incorporated for smooth, quiet and fast speed autofocusing and also permits full-time manual focusing even during autofocusing. The wide, easy-to-grip manual focusing ring delivers smooth and positive manual focusing operation even if you are using a glove or protective measure in certain difficult shooting environment (such as underwater housing). In short, this high-performance lens is capable of providing top-level image quality and superb operability while maintaining a relatively compact size as compared to the similar fast speed f/2.8
L-zoom counterpart.

The fast lens speed of f/2.8 and couples with USM can let you crop tightly to exclude distracting background detail and emphasize appealing subject areas in a responsive manner during shootings. Technically, fixed single focal length lenses also give you faster shutter speeds than many budget zooms for fast-action snaps. The lens also has a built-in telescopic lens hood and eliminates the space and needs for carrying another accessory for possible backlit shooting. It also has a focus limiter designed to offer photographer with swifter in presetting two scales of focusing distances. It is rigid, extremely well made and optically, it matches the physical quality presents and a clear favorite for those who still holds a strong belief that prime is better than zoom...as it certainly requires some justification of why despite all the benefits of an equivalent class of high performance zoom can provide, users are still locking in with this lense. Price and weight, I think...Well, if that is not an issue, what about the
Canon EF 200mm f/1.8L USM ? hehe ..

So, Canon actually offers two options for photographers at the prime 200mm focal length. Each with a different configurations (but share many similarities in Canon innovations/features) other than in their lens speed, size,weight and price to fit individual needs. I would think the L-designation would make between them of a less significant factor on their respective optical performance, but rather, the applications in finding good use of them on the working field..

SPOUTS  by Mark_Schretlen (68k Jpeg) Loading ...
Spouts ...

Witless Bay Ecological Reserve
Avalon Peninsula, Newfoundland


Credit
: Image courtesy of Mark Schretlen from Canada whose PORTFOLIO can be accessed at PBase. Image copyright © 2006. All rights reserved. Please respect the visual property of the contributing photographer.

Sexy Zebras at Canon event .. by Caveman LEE (88k) jpeg. Loading ......
Technical Specification for Canon EF 200mm f/2.8L USM (ORIGINAL version) Telephoto: -

Type: - Autofocus lens type with manual focusing mechanism
Focal Length: Fixed focal length 200mm
Focus Adjustment:- Autofocus ; USM with Inner and rear focus design; dual Focusing range limiter
Manual Focusing:- possible via AF/M switch and electronic full-time manual focusing possible via focusing ring
Zoom Adjustment:- Nil. Fixed Focal Length Lens
Closest Focusing Distance:- 1.5m (4.9ft)
Maximum Magnification:- 0.16X
Drive System:- USM with full-time manual focusing
Distance Scales: Provided via window on metres/feet.
Angle of View:- 10°
7° 12° (horizontal, vertical and diagonal)
Aperture range:- f/2.8 - f/32
Number of Diaphragm Blades: - 8 blades
Minimum Aperture: - f/32
Filter rotation: NoFilter Attachment Size:- 72mm front mounting
Lens construction:- 9 Elements in 7 Groups with Two UD glass elements (at 2nd and 4th)

Credit: Image courtesy of CAVEMAN LEE where I found this lovely photo from his PORTFOLIO at PBase. Image copyright © 2006. All rights reserved. Please respect the visual property of the contributing photographer.

Optical Contruction of original version MTF for original EF 200mm f/2.8L
Extenders: Usable. Extender EF 1.4X:- focal length multiplication: 280mm f/4 ~f/45, AF retained, Magnification ratio: max. 0.22X; Extender EF 2.0X: focal length multiplication: 400mm f/5.6~f/64, AF retained; Magnification ratio: max. 0.32X;
Others: - Extension Tube Extension Tube EF25 (II) 0.31X
Diameter:- 136.2mm x 83mm; Weight:- 790g
Accessories:- Lens Cap/pouch E-72U (supplied ); lens hard case: LH-D18; lens Hood:- Built-in; Soft Case:- nil.

Status:
Discontinued.

Previous | NEXT | 2/3 The MK II (current version) of the Canon EF 200mm f/2.8L

Part One | Part Two | Part Three
